OMO-D360 Product Full Parameters (English Version)

Model: OMO-D360 Rotating Gimbal Version

Product Description: High-Definition High-Brightness Smart Projector

Core Configuration

CPU: T950S Quad-core ARM Cortex-A53 Processor, ARMv8-A Architecture with Neon Extension

GPU: Quad-core ARM Mali-450MP GPU, supports OpenGL ES 3.2, Vulkan 1.1 and OpenGL ES 2.0

Projection Specifications

Projection Technology: 2.1-inch 720P LCD TFT Display

Projection Light Source: RGB LED

Light Source Lifespan: Up to 30,000 hours

Light Source Brightness: 4000 Lumens (140 ANSI Lumens)

Lamp Type: LED

Native Resolution: 1280*720

Projection Size: 30-200 inches

Contrast Ratio: 2000:1

Throw Ratio: 1.28:1 (35 inches at 1 meter projection distance)

Distortion Rate: <1.0%

Brightness Uniformity: >75%

Projection Distance: 0.8-4 meters

Aspect Ratio: 16:9

Focus Mode: Auto Focus

Keystone Correction: ±30° vertical, ±30° horizontal, multi-angle adjustment

Projection Mode: Front Projection

System Parameters

Screen Mirroring: Supports AirPlay/MiraCast

Operating System: Android 13.0

CPU: T950S

RAM: 2GB LPDDR3

Internal Storage: 16GB

Wi-Fi: 2.4G/5G Dual-band

Bluetooth: BT 5.0

Basic Parameters

Supported Video Formats: H.265 HEVC MP-10@L5.0 up to 4Kx2K@30fps, VP9 Profile 2-10 up to 1080p@60fps, H.264 AVC HP@L4.2 up to 1080p@60fps, H.264 MVC up to 1080p@60fps, MPEG-4 ASP@L5 up to 1080P@60fps, WMV/VC-1 SP/MP/AP up to 1080P@60fps, AVS-P16(AVS+)/AVS-P2 up to 1080P@60fps, MPEG-2 MP/HL up to 1080P@60fps, MPEG-1 MP/HL up to 1080P@60fps

Supported Audio Formats: MP3, AAC, WMA, RM, FLAC, Ogg, supports Dolby Audio, compatible with 7.1/5.1 channel downmix

Supported Image Formats: Supports JPG, PNG, BMP and other image formats for browsing

External Storage: Supports USB 2.0 and mobile hard drives

Remote Control: Supports Infrared (IR) remote control and Bluetooth wireless remote control

Built-in Speaker: 3W

Total Power Consumption: 40W

Interfaces: 1 x USB 2.0 interface, supports data reading from USB storage devices

Product Dimensions: 15.6125.7149.8mm

Package Dimensions: 183185163mm

Net Weight: 1.26KG

Packaging Specifications: 20 units per carton, outer carton size 734042CM, outer carton weight 26.5KG
